Parts List 8.2 WorkCentre 3325 Lower DADF
Item Name Part Number
0 Lower DADF
1 DADF Lower Cover
2 White Bar Plate 025N00105
3 P/UP Separate ETC Spring
4 E Ring
5 6 D Bush
6 Exit Feed Ground
7 DADF Ground
8 D Idle Feed Gear
9 Feed Gear MEA
10 Exit Gear
11 C Idle Feed Gear
12 Feed Actuator
13 DADF Registration Sensor
14 Feed Roller 022N02681
15 Regi Actuator
16 Doc Torsion Etc Spring
17 Middle Roller
18 DADF Middle Roller
19 Exit Roller
20 Taptype Screw
21 Upper DADF Damper
22 CS Ring
23 Plain Washer
24 DADF Feed Sensor
