Parts List 8.4 WorkCentre 3325 Platen DADF
Item Name Part Number
0 Platen DADF
2 Platen Cover
3 Extension L Guide
4 Extension S Guide
5 Lifting DADF Sponge
6 Lifting Exit Lever
7 Solenoid Pad
8 Lifting Solenoid 121N01160
9 Platen Ground
10 Idle Mid ETC Spring
11 Idle Roller
12 SCF M Idle Roller
13 Idle Feed Shaft
14 Jam Feed Lever
15 ES Spring
16 Sponge White Sheet1
17 Platen DADF Sponge
18 Platen Damper
19 Machine Screw
