Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-57
Parts List 10.1 WorkCentre 3325 Scanner
Item Name Part Number
0 MFA
1 Taptype Screw
2 Control Panel
2.2 Control Panel Cover (Outside)
WorkCentre 3325DN Control Panel Cover
110V (Inside)
220V (Inside)
WorkCentre 3325DNI Control Panel Cover
110V (Inside)
220V (Inside)
101N01469
101N01468
002N03065
101N01463
101N01464
2.3 Function Key
2.4 LCD Holder
2.5 LCD Bracket
2.6 LCD (3315 & 3325) 123N00264
2.7 LCD Sponge
2.8 Fax Key
2.9 Circle Key
2.10 OK Key
2.11 Numerical Key
2.12 Back Key
2.13 Start Key
2.14 Stop Key
2.15 Power Key
2.16 Power B Key
2.17 4 Line Status Lens
2.18 Control Panel Board 140N63634
2.19 Taptype Screw
3 Scanner
3.1 DADF
3.2 Connector Cover
3.3 Platen
