Xerox WorkCentre 7545 Secure Installation And Operation

4
• At the Web UI
5
, select the Properties tab.
• Select the following entries from the Properties 'Content menu’: Connectivity  Protocols  IP.(Internet Protocol)
• Enter the domain name in the ‘Domain Name’ text box and the machine name in the ‘Host Name’ text box inside the
General group box.
• Select the [Apply] button to save the domain and host names entered.
l). When utilizing Secure Sockets Layer (SSL):
• For the purposes of the evaluation, the maximum validity of digital certificates was set to 180 days.
• If a self-signed certificate is to be used the generic Xerox root CA certificate should be downloaded from the device and
installed in the certificate store of the user's browser.
m). HTTPS is enabled in the evaluated configuration. To enable HTTPS (SSL):
• At the Web UI, select the Properties tab.
• Follow the “Security Certificates” instructions starting on page 88 of the SAG to install on the device either a self-signed
digital certificate or a digital certificate signed by a Certificate Authority (CA).
• Select the following entries from the Properties 'Content menu’: Connectivity  Protocols  HTTP.
• Select the Secure HTTP (SSL) Enabled checkbox in the Configuration group box and enter the desired HTTPS port
number in the Port Number text box.
• Select the [Apply] button.
n). When utilizing Secure Sockets Layer (SSL) for secure scanning:
• SSL should be enabled and used for secure transmission of scan jobs.
• When storing scanned images to a remote repository using an https: connection, a Trusted Certificate Authority
certificate should be uploaded to the device so the device can verify the certificate provided by the remote repository.
• When an SSL certificate for a remote SSL repository fails its validation checks the associated scan job will be deleted
and not transferred to the remote SSL repository. The System Administrator should be aware that in this case the job
status reported in the Completed Job Log for this job will read: “Job could not be sent as a connection to the server
could not be established”.
o). To be consistent with the evaluated configuration, the HTTPS protocol should be used to send scan jobs to a remote IT
product.
p). To be consistent with the evaluated configuration, protocol choices for remote authentication should be limited to
[Kerberos (Solaris)], [Kerberos (Windows)] or [LDAP]. The device supports other protocol options. Choose the protocol
option that best suits your needs. The System Administrator should be aware, however, that remote authentication using
Kerberos will not work with Windows Server 2003.
In the case of LDAP/LDAPS the System Administrator should ensure that SSL is enabled as discussed in Step 5 under
“Configuring LDAP Server Optional Information” on page 46 in the SAG. Make sure that [Enable SSL] under SSL is selected.
q). To be consistent with the evaluated configuration, the device should be set for local authorization. Remote authorization
was not evaluated since that function is performed external to the system. Choose the authorization option that best suits
your needs.
r). As part of the evaluated configuration, encryption of transmitted and stored data by the device must meet the FIPS 140-2
Standard. To enable the use of encryption in “FIPS 140 mode” and check for compliance of certificates stored on the device
to the FIPS 140-2 Standard follow the instructions on page 76 of the SAG.
Note that the Mocana crypto module that implements IPSec and Disk Encryption was validated for the operating
environment that corresponds to the one used on this product. However, as of this date the operating environment used on
this product differs in terms of Linux flavor and CPU from that which the OpenSSL crypto module that implements SSL was
validated against.
s). In viewing the Audit Log the System Administrator should note the following:
• Deletion of a file from Reprint Saved Job folders or deletion of a Reprint Saved Job folder itself is recorded in the Audit
Log.
5
From here on the directions assume that the Web UI has been accessed already by following the “Accessing CentreWare IS” instructions on page
17 of the SAG.

Xerox WorkCentre 7545 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Print speed (black, normal quality, A4/US Letter)	45 ppm
Languages support	CZE, DAN, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUM, RUS, SWE, TUR
Scan file formats	JPG, PDF, TIFF, XPS
Dimensions (WxDxH)	1064 x 685 x 1127 mm
Printer management	SNMP, MIB
Networking features	Gigabit Ethernet
All-in-one functions	Copy, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, print, scan
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	200000 pages per month
Optional functions	Fax
Number of print cartridges	4
Page description languages	HP-GL/2, Microsoft XPS, PCL 5c, PCL 6, PostScript 3, TIFF
Copier resize	25 - 400 %
Maximum number of copies	9999 copies
Time to first copy (black, normal)	6.6 s
Time to first copy (color, normal)	7.8 s
Copy speed (black, normal quality, A4)	45 cpm
Scan to	E-mail, FTP, USB
Input color depth	24 bit
Maximum scan area	A3 (297 x 420) mm
Scan speed (color)	70 ppm
Image formats supported	JPG, TIF
Optical scanning resolution	600 x 600 DPI
Paper input type	Paper tray
Total input capacity	620 sheets
Total output capacity	1120 sheets
Maximum input capacity	5140 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	110 sheets
Envelopes sizes	C5, DL
Custom media width	140 - 297 mm
Maximum print size	297 x 420 mm
Custom media length	182 - 432 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Plain paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Display	-
Control type	Touch
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Authentication method	NDS/LDAP/Kerberos/SMB
Internal memory	3072 MB
Internal storage capacity	160 GB
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	18 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	9.1 W
Power consumption (standby)	130 W
Power consumption (PowerSave)	82 W
Power consumption (average operating)	984 W
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Linux operating systems supported	Fedora 7, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, Solaris 10 U4, Solaris 10 U5, SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Certification	FCC, ICES, TUV, CB, GOST, NOM, CE, EAL3
