8-11
Exploded View & Parts List
Service Manual
No. Description SEC.Code Q’ty SA Remark
36 WASHER-PLAIN 6031-001051 1 X
37 LABEL(R)-HV FUSER JC68-00407A 1 X
38 SCREW-TAPTITE 6006-001078 1 X
39 SCREW-MACHINE 6006-001193 5 X
40 SCREW-TAPTITE 6603-000269 6 X
41 SCREW-TAPTITE 6003-000196 1 X
Fuser Unit Assembly Parts List
SA : Service Available
O : Service available X : Service not available
