Xerox WorkCentre PE114e User Manual

3-4
Specifications
Service Manual
3.5 Paper Handiling Specification
Items SCX-4100 Remarks
Paper Handling Capacity( 20lbs) Main Tray 250sheets
Bypass(MP Tray) Single Sheet
Optional Cassette No
Output Capacity Face Down: 50Sheets/20lb
Face Up: 1Sheet
Output Control Face down/Face up
Paper Size Main Tray Legal,A4,Letter, Folio,
Executive, B5, A5, A6
Bypass Bypass:Envelope6 3/4, 7
With main tray paper
3/4,#9, #10,DL,C5,B5
Paper Weight Main Tray 16~24 lb.
Bypass 16~43 lb.
Paper Path Standard output Bottom to Top Front (FIFO)
Straight Through Face up, Single Sheet
Paper Size Max 216 x 356mm(8.5"x14")
Min 76 x 127mm(3"x5")
Compatibility DOS No

Xerox WorkCentre PE114e Specifications

General

Brand	Xerox
Model	WorkCentre PE114e
Category	Printer
Language	English
