8-3
EXPLODED VIEW & PARTS LIST
Service Manual
Main Assembly Parts List
SA : Service Available
O : Service available X : Service not available
No. Description SEC.Code Q’ty SA Remark
0 SET SCX-4100/XRX
SCX-4100/XRH
1 MEA UNIT-COVER MIDDLE JC97-01958E 1 O SCX-4100
2 MEA UNIT-COVER REAR JC97-01959B 1 O SCX-4100
2-1 COVER-M_REAR JC63-00475B 1 X
2-2 COVER-M_REAR DOOR JC63-00476B 1 X
3 COVER-M_SIDE_L JC63-00472B 1 O
4 COVER-M_SIDE_R JC63-00471B 1 O
5 MEA UNIT-COVER FRONT JC97-01960B 1 O SCX-4100
5-1 COVER-M_FRONT JC63-00477B 1 X
5-2 ADJUST-M_MANUAL_L JC70-00481B 1 X
5-3 ADJUST-M_MANUAL_R JC70-00482B 1 X
5-4 ADJUST RACK-M_MANUAL JC70-00304A 2 X
5-5 GEAR-RACK PINION JC66-00387A 1 X
S SCREW-TAPTITE 6003-000264 3 X
6 MEA UNIT-CASSETTE_MB JC97-01914B 1 O SCX-4100
7 UNIT-HUMMING_VE LSU JC59-00018C 1 O
8 MEA ETC-TR JC81-01765A 1 X
8-1 ROLLER-TRANSFER JC66-00725A 1 O
8-2 GEAR-TRANSFER JC66-00395A 1 O
8-3 PPR-SPACER-TR JC72-00851A 2 X
9 ELA-UNIT-DRIVE JC96-03138A 1 O
10 ELA-UNIT-COVER PLATEN JC96-03050B 1 O
11 CBF JARMESS-LSU JC39-00242A 1 O
12 FAN-DC 3103-001085 1 O
13 PBA MAIN-CONTROLLER JC92-01594B 1 O
14 MEA UNIT-SHIELD ENGINE JC97-01792A 1 O
15 BRACLET-P-INLET JC61-00601A 1 O
16 SMPS-V1, 110V JC44-00072A 1 O 110V
SMPS-V2, 220V JC44-00073A 1 O 220V
17 CBF HARNESS-ENGINE JC39-00240A 1 O
To Next Page
