Z-2 User Manual
Con󽗉guration & Upgrading
Ensure the gimbal and the GCU have both been upgraded to the latest
󽗉rmware before use. Otherwise, usage may be a󽗈ected.
Ensure the diver of the config module is installed on the computer
before con󽗉guration or upgrading.
Before con󽗉guration, the computer should be set to a static IP address,
which is in the same network segment with the GCU (without IP
address con󽗊icts). The default IP address of the GCU is 192.168.144.108
Do not power o󽗈 the device while upgrading. Restart the device once
the upgrading is complete.
1. Connect the computer and ETH port with the Network Conversion Module.
Power on the devices.
2. Run the Dragon󽗊y display and control software to con󽗉rm that it is
connected to the pod. Open the settings page.
3. When the settings are complete, click "Save".
4. Restart the pod to enable the con󽗉gurations to take e󽗈ect.
For instructions on Net Settings, CAMERA, S.BUS Setting, Calibration,
Carrier, and Advance, please refer to the 《 Dragon󽗊y Quick Start Guide
》- Ribbon - Settings, or visit the www.allxianfei.com to get information
in the Video Center.
Before performing the 󽗉rmware upgrade, please make sure that the
Dragon󽗊y software is turned o󽗈.
GCU Upgrading
1. Connect the computer and ETH port with the Network Conversion Module.
Power on the devices.
2. Run the GCU Upgrade Tool.
