DC IN HDMI 1 HDMI 2 DP
(HDMI 1.4) (HDMI 2.1) (DP1.2)
Connecting the DP cable. The DP cable is only used for transferring data or signals via the DP port.
a. Make sure the monitor and the computer are both turned off.
b. Connect one end of the DP cable to the computer's DP port, and the other end to the monitor's DP port.
Note: The maximum resolution of the DP port (DP 1.2) is 2560 × 1080, and the maximum refresh rate is 200 Hz.
Connecting the HDMI cable. The HDMI cable is only used for transferring data or signals via the HDMI port.
It is sold separately.
a. Make sure the monitor and the computer are both turned off.
b. Connect one end of the HDMI cable to the computer's HDMI port, and the other end to the monitor's
HDMI port.
Note: Due to the detailed classification of the HDMI certification standard, HDMI 2.1 is divided into TMDS
protocol (its bandwidth is equivalent to HDMI 2.0's) and FRL protocol. The monitor's HDMI 2.1 port
supports the TMDS protocol. The maximum resolution of the HDMI 2.1 port is 2560 x 1080, and the
maximum refresh rate is 180 Hz. The maximum resolution of the HDMI 1.4 port is 2560 × 1080, and
the maximum refresh rate is 75 Hz. The FreeSync Premium function cannot be enabled when this
port is used.
Plug both the power cords of the computer and the monitor into a power outlet.
Earphone
DC Power Cord
Connect a headset or any 3.5 mm compatible external audio device to the monitor's audio output port.
Note: The audio port is only for transmitting the audio data
Note: If the power adapter cord or DP cable is damaged, it must be replaced with a genuine
one purchased from the manufacturer or after-sales service department
