30
1，4
Static Return To Off SRO sequencing error
1
Improper sequence of
KSI,INTERLOCK,F/R
2 Wrong SRO type selected.
3 Direction switch malfunction.
4 Sequencing delay too short.
2，1
Throttle Wiper High
Accelerator voltage is too
high.
1 Accelerator is damaged.
2 Wrong accelerator type selected.
2，2
EMR Wiring Open EMR wiring fault 1 EMR wire or check wire broken.
2，3
High Pedal Disable HPD
1
Incorrect sequence of accelerator and
KSI,INTERLOCK.
2 Wrong HPD type selected.
3 Accelerator malfunction
4 Key switch and INTERLOCK power-off.
5 Sequencing delay too short.
6 Wrong accelerator type selected.
2，4
Throttle Wiper Low
Accelerator voltage is too
low.
1 Accelerator is damaged.
2 Wrong accelerator type selected.
3，1
Multiplexer Fault Multiplexer malfunction Multiplexer malfunction
3，2
Main Contactor
Misssing or welded main
contactor.
1 Main contactor coil open.
2 Main contactor stuck closed
3 Welded main contactor
4 Main contactor driver shorted.
Precharge Precharge fault 1 Controller defective.
2 Low battery voltage.
3，3
Brake Fault Electromagnetic brake fault. 1 Brake coil shorted or open.
2 Brake driver fault.
4，1
Service Total Disable
Total KSI timer has expi
red. Expired total KSI timer.
Service Driver Disable
Total driving timer has
expired.
Total driving timer has expired.
Service Total Expired
Setted (KSI) service timer
has expired.
Setted (KSI) service timer has expired.
Service Driver Expired
Setted (driver)
service timer
has expired.
Setted (driver) service timer has expired.
4，2
Battery Over voltage Battery voltage is too high. Battery voltage is too high.
Battery Under voltage Battery voltage is too low. 1 Battery voltage is too low.
2 Corroded battery terminal.
3 Storage battery is damaged.
4，3
Temperature Cutback
Controller heatsink is too hot
or too cold.
1 The power of controller is small.
2 Excessive load on vehicle fo a long time.
3 Abstraction of heat is bad.
