14.2 Lists of CDDR （
（（
（with full free lift）
））
）accessories, spare parts and vulnerable parts
No. Name Use position
Type &
specification
Quantity Remarks
1 Key to the electric lock
Unlock the
electric lock
2
2
Charging plug and
socket
Matched with the
charger
1 set
With no
charger for
built-in type
3 Fuse
Electric
equipment
10A 2
4 Fuse
Electric
equipment
100A 1 standard
5 Fuse
Electric
equipment
180A/425A 1
standard/high-
standard
6 Sealing ring Oil cylinder UHS27 2
7 O type sealing ring Oil cylinder 45X2.65 2
8 O type sealing ring Oil cylinder 14X2.65 1
9 Composite ring
Oil inlet of
cylinder
D16 2
10 Dustproof ring Oil cylinder DH27 2
15．
．．
．Structure diagram (explosion diagram) and principle diagram
of the major parts
See attached diagram I for “The principle diagram of hydraulic system”
See Electric Instructions for “Instruction of the electric system”
See attached diagram II for “The explosion diagram”
