Xilin CDDR - 1.2 Main Technical Parameters

4
1.2 Main technical parameters（
（（
（CDDR Electric Pallet Stacker）
））
）
Characteristics
1.1 Manufacturer(abbreviated) Ningbo Ruyi Ningbo Ruyi
1.2 Model CDDR10-I(high standard)
CDDR10-II（standard）
1.3
Driving model：Electric(Storage battery),
diesel,
gasoline, fuel gas
Electric(storage battery) Electric(storage battery)
1.4
Driving model（Manual, Walking, Stand driving, Seat
driving
,Order picking
）
walking walking
1.5 Rated load Q(kg) 1000 1000
1.6 Load center distance c (mm) 600 600
1.8 Front overhang x (mm) 697 697
1.9 Tread Y (mm) 1383 1383
Weight
2.1 Service weight(with battery) kg 1220/1245/1260/1270 1160/1185/1200/1210
2.2 Axle load, front/rear, laden kg 1470/1310 1440/1280
2.3 Axle load, front/rear, unladen kg 900/380 870/350
Wheel chassis
3.1
Wheels (rubber, high elasticity, pneumatic tyre,
polyurethane wheel)
polyurethane polyurethane
3.2 Wheel dimension, front φ250×70 φ250×70
3.3 Wheel dimension, rear φ80×84 φ80×84
3.4 Additional wheel(dimension) φ150×60 φ150×60
3.5
Wheel number, front/rear （x = driving wheel）
1x+1/4 1x+1/4
3.6 Tread, front b
10
(mm) 520 520
3.7 Tread, rear b
11
(mm) 404/525 404/525
Dimension
4.2 Height of mast, lowered h
1
(mm) 1735/1985/2135/2235 1735/1985/2135/2235
4.3 Free lift height( optional) h
2
(mm) 1300/1550/1700/1800 1300/1550/1700/1800
4.4 Lift height h
3
(mm) 2500/3000/3300/3500 2500/3000/3300/3500
4.5 Max. height of mast, extended h
4
(mm) 2955/3455/3755/3955 2955/3455/3755/3955
4.9
Min. /Max. height of operation handle, in driving position
h
14
(mm) 670/1300 670/1300
4.15 Height, lowered h
13
(mm) 90 90
4.19 Overall length l
1
(mm) 1950 1950
4.20 Length to fork face l
2
(mm) 878 878
4.21 Overall width of truck body b
1
(mm) 820 820
4.22 Fork dimension s/e/l(mm) 60/180/1070(1150) 60/180/1070(1150)
4.25 Overall width of fork b
5
(mm) 570/695 570/695
4.32 Wheelbase ground distance m
2
(mm) 31 31
4.33 Aisle width, with pallet 1000x1200 crosswise A
st
(mm) 2450 2450
4.34 Aisle width, with pallet 800x1200 lengthwise A
st
(mm) 2420 2420
4.35 Turning radius W
a
(mm) 1575 1575
Performance
Data
5.1 Traveling speed, laden/unladen Km/h 5.8/6 5.8/6
5.2 Lifting speed, laden/unladen m/s 0--0.12/0--0.19 0.11/0.20
5.3 Descending speed, laden/ unladen m/s 0--0.35/0--0.12 0.12/0.12
5.8 Max. gradeability, laden/unladen % 8/15 6/10
5.10 Traveling brake Electromagnetic brake Electromagnetic brake
Motor
6.1 Driving motor power kW 1.6(AC) 1.2(AC)
6.2 Lifting motor power kW 3 3
6.4 Battery voltage/rated capacity V/Ah 24/240 24/200
6.5 Battery weight kg 240 200
Battery dimension（LXWXH）
mm 675×254×500 675×254×500
8.4 Noise level at operator’s ear, according to DIN12053 dB(A) 65 65
1.Parameters relating to h1、l、Q shall be calculated according to h1=3000mm and l=1070mm.
