Xilinx Alveo U50 Installation Guide

Figure 2: Alveo U50DD ES Card with Half-Height Bracket
CAUTION! Alveo accelerator cards are designed to be installed into a data center server, where controlled
air ow provides direct cooling. If the cooling enclosure is removed from the card and the card is powered-
up, external fan cooling airow MUST be applied to prevent over-temperature shut-down and possible
damage to the card electronics. Removing the cooling enclosure voids the board warranty.
For card specicaons, dimensions, list of card features, and block diagram, see Alveo U50 Data
Center Accelerator Cards Data Sheet (DS965).
Chapter 2: Card Interfaces and Details
UG1370 (v1.7) December 9, 2020 www.xilinx.com
Alveo U50 Data Center Accelerator Card Installation Guide 10
Send Feedback

Xilinx Alveo U50 Specifications

General

Brand	Xilinx
Model	Alveo U50
Category	Computer Hardware
Language	English
