Xinje DS5L Series User Manual

149
U0-21
Input signal status 1
U0-22
Input signal status 2
U0-23
output signal status 1
U0-24
ouput signal status 2
U0-25
Input pulse frequency
(0000～9999)*1
1Hz
U0-26
(0000～9999)*10000
U0-37
VREF AD Raw value
U0-38
TREF AD Raw value
U0-41
Instantaneous output power
1W
U0-42
Average output power
1W
U0-43
Instantaneous thermal power
1W
U0-44
average thermal power
1W
U0-49
position feedforward
1 command
unit
U0-50
speed feedforward
rpm
U0-51
torque feedforward
% rated
U0-52
Instantaneous Bus Capacitor Power
1W
U0-53
Average Bus Capacitor Power
1W
U0-55
Discharge power of instantaneous regenerative braking
1W
U0-56
Average regenerative brake discharge power
1W
U0-57
Absolute encoder present position
feedback low 32-bit
(0000～65536)*1
Encoder pulse
U0-58
(0000～65536)*10000
U0-59
Absolute encoder present position
feedback high 32-bit
(0000～65536)*1
Encoder pulse
U0-60
(0000～65536)*10000
U0-61
Xnet communication error amounts
U0-62
Xnet Communication Waiting Synchronization Frame State Interference
U0-63
Xnet Communication Waiting for Synchronization Frame State
Receiving Data Frame
U0-64
Xnet Communication Waiting Data Frame State Interference
U0-65
Xnet Communication Waiting for Data Frame Status Receive
Synchronized Frame
U0-66
Xnet communication CRC parity error
U0-67
Xnet communication UART error
U0-68
Xnet communication timeout counting
U0-69
communication encoder timeout counting
U0-89
Real-time speed feedback (displaying range -99.99~99.99rpm)
0.01rpm
U0-91
Multi-circle absolute motor circles
U1-XX：
Code
Contents
Unit
U1-00
present alarm code
U1-01
present warning code
U1-02
U phase current when alarming
0.01A
U1-03
V phase current when alarming
0.01A
U1-04
bus voltage when alarming
V
U1-05
IGBT temperature when alarming
℃
U1-06
torque current when alarming
0.01A
U1-07
excitation current when alarming
A
