V5 series inverter
41
terminal 2
3: Multi-speed control
terminal 3
4: Exteral forward jog in-
put
5: Exteral reverse jog input
6: Acc/Dec time terminal 1
7: Acc/Dec time terminal 2
8: Acc/Dec time terminal 3
9: 3-wire operation control
10: Free stop (FRS)
11: External stop command
12: DC brake input com-
mand DB
13: Inverter running prohi-
bition
14: Frequency up (UP)
15: Frequency down
(DOWN)
16: Acc/Dec prohibition
17: External reset (clear
fault)
18: External fault signal
(normal open)
19: Frequency setting
channel 1
20: Frequency setting
channel 2
21: Frequency setting
channel 3
22: command switch to
terminal
23: running command
channel 1
24: running command
channel 2
25: swing frequency selec-
tion
26: Reset swing frequency
state
27: Close-loop disabled
28: simple PLC pause
command
29: PLC disabled
30: Reset PLC stopping
status
31: Frequency switch to CI
32: Counter trigger signal
input
