Xinje VB5 User Manual

V5 series inverter
42
33: Counter reset input
34: External interrupt input
35: Pulse frequency input
(only valid for X6)
36: Actual length reset
input
P4.01 Function selection of
input terminal X2
Ditto
1 2 ×
P4.02 Function selection of
input terminal X3
Ditto
1 3 ×
P4.03 Function selection of
input terminal X4
Ditto
1 10 ×
P4.04 Function selection of
input terminal X5
Ditto
1 17 ×
P4.05 Function selection of
input terminal X6
Ditto
1 18 ×
P4.06 Function selection of
input terminal X7 FWD
Ditto
1 0 ×
P4.07 Function selection of
input terminal X8 REV
Ditto
1 0 ×
P4.08 FWD/REV
Operation mode selection
0: 2-wire control mode 1
1: 2-wire control mode 2
2: 3-wire control mode 1
3: 3-wire control mode 2
1 0 ×
P4.09 UP/DOWN speed 0.01－99.99Hz/s 0.01 1.00Hz/s ○
P4.10 Bi-direction
open-collector output
terminal OC
0: Inverter running (RUN)
1: Frequency arriving sig-
nal (FAR)
2: Frequency level detec-
tion (FDT1)
3: Frequency level detec-
tion (FDT2)
4: Overload pre-alarm (OL)
5: Inverter under voltage
blockade and stop (LU)
6: External fault stop
(EXT)
7: Output frequency arrive
upper limit (FH)
8: Output frequency arrive
lower limit (FL)
9: Inverter zero speed run-
ning
10: Simple PLC running
finished
11: PLC one period run-
ning is completed
12:reach the setting count
value
1 0 ×
