Xinje VB5 User Manual

V5 series inverter
43
13: Mid counting value
arrived
14: Inverter running prepa-
ration is finished (RDY)
15: Inverter fault
16: Running with start
frenquence
17: DC brake when startup
18: brake when stop
19: High and low limit of
swing frequency
20: set running time arrived
P4.11 Relay output selector Ditto 1 15 ×
P4.12 Detecting range of fre-
quency arrived (FAR)
0.00~50.00Hz
0.01Hz 5.00Hz ○
P4.13 FDT1 (frequency) vol-
tage
0.00~upper limit of of fre-
quency
0.01Hz 10.00Hz ○
P4.14 FDT1 lag 0.00~50.00Hz 0.01Hz 1.00Hz ○
P4.15 FDT2 (frequency) vol-
tage
0.00~upper limit of of fre-
quency
0.01Hz 10.00Hz ○
P4.16 FDT2 lag 0.00~50.00Hz 0.01Hz 1.00Hz ○
P4.17 Analog output (AO) 0: Output frequency
(0~max frequency)
1: Output current (0~2
times of rated current)
2: Output voltage (0~1.2
inverter rated voltage)
3: Bus voltage (0~800V)
4: PID setting
5: PID feedback
6: VI (0~10V)
7: CI (0~10V/4~20mA)
1 0 ○
P4.18 Analog output (AO) gain
0.50~2.00 0.01 1.00 ○
P4.19 AO output mode 0: 4~20mA
1: 0~10V
- 1 ○
P4.20 DO output terminal 0: Output frequency
(0~upper limit frequency)
1: Output current (0~2
times motor rated current)
2: Output voltage (0~1.2
inverter rated voltage)
3: Bus voltage (0~800V)
4: PID setting
5: PID feedback
6: VI (0~10V)
7: CI (0~10V/4~20mA)
100: inverter is running
(RUN)
1 0 ○
