Xinje VB5 User Manual

V5 series inverter
45
6. Protective function parameters (Group P5)
Group P5: Protective function parameters
Parameter Name Range
Minmum
unit
Default setting
Change
P5.00 Motor overload protection
mode selection
0: Inverter lock the output
1: Disabled
1 0 ×
P5.01 Motor overload protection
coefficient
20~120% 1 100% ×
P5.02 Over-voltage speed loss
selection
0: Disabled
1: Enabled
1 1 ×
P5.03 Speed loss over-voltage
point
380V: 120~150%
220V: 110~130%
1% 140%
120%
○
P5.04 Auto current limiting 110%~200% 1% 150% ×
P5.05 Frequeny decrease rate
when current limiting
0.00～99.99Hz/s 0.01Hz/s 10.00Hz/s ○
P5.06 Auto current limiting se-
lection
0: constant speed invalid
1: constant speed valid
Note: Acc/Dec is valid
1 1 ×
P5.07 Restart after power off 0: no action
1: action
1 0 ×
P5.08 wait time of restart after
power off
0.0~10.0s
0.1s 0.5s ×
P5.09 Error auto recover times 0~10
0: No auto recover function
(Note: overload and overheat
have no recovery function)
1 0 ×
P5.10 Error auto recover interval
time
0.5~20.0s 0.1s 5.0s ×
7. Fault recording parameter (Group P6)
Group P6: Fault recording parameter
Parameter Name Description
Minmun unit Default
setting
Change
P6.00 Previous fault record Previous fault record 1 0 *
P6.01 Output frequency of pre-
vious fault
Output frequency of previous fault
record
0.01Hz 0 *
P6.02 Setting frequency of pre-
vious fault
Setting frequency of previous fault
record
0.01Hz 0 *
P6.03 Output current of previous
fault
Output current of previous fault
0.1A 0 *
P6.04 Output voltage of previous
fault
Output voltage of previous fault
1V 0 *
P6.05 DC bus voltage of pre-
vious fault
DC bus voltage of previous fault
1V 0 *
P6.06 Module temperature of
previous fault
Module temperature of previous
fault
10C 0 *
