38
1. Select com port
Before downloading the screen, select the correct com port. The port is DB9 pins serial port of PC.
The computer will select the port automatically, user only need to know the port number. If user
can not confirm which port to use, try each port in file. If the com port is wrong, it will prompt
you with the note “can not open”:
Click “file”-“comm port…” to select the correct com port:
2. download
Connect the XP/XMP DB9 pins com port and PC serial port using download cable. Power on the
XP/XMP, click
to start downloading:
If the downloading is completed, it will pop up below window:
Attention:
(1) Do not cut the power when downloading, or you have to download again
(2) The downloading cable of downloading OP screen is the same as downloading PLC program
(3) Do not download when XCPPro and OP software are both opened
Screen download
