ENG-13
English
Powering and installation
CONNECTIONS
Plug one end of the AC/DC power adaptor into the DC IN 9-12V jack on the right of the unit, then plug
the other end into the AC power receptacle. Please refer to the following illustration.
If using car cigarette lighter adaptor to connect to the power:
Plug one end of the cigarette lighter adaptor into the DC IN 12V jack on the unit, plug the
other end into the car cigarette lighter socket.See illustration below.
Note:
1.Car cigarette lighter adaptor is not recommended to recharge the battery.
2.Car cigarette light adaptor can only be used when the car power supply is 12V.
3.The mains plug is
