30
When connected, the MI-6 pinpointer transmits its audio signal directly to ; a new menu will now
be available with extended functions. (refer to the MI-6 Manual)
PINPOINTER
The MI-6 has 50 levels of sensitivity via the WS6 MASTER.
Press
and
to increase or decrease the MI-6 sensitivity.
RETUNE: Recalibrate the MI-6 threshold regularly by pressing its button very briefly, keep-
ing away from any metallic source.
Modify the low/high audio tone of the PULSE Mode from 100 to 1582 Hz.
Press
and
to adjust the tone.
Sensitivity
Tone
Audio PITCH/Audio PULSE
Audio PITCH : The sound varies in tone and intensity, it is the default mode and offers fast
target location.
Audio PULSE : Has a higher sound, intended for noisy environments. Target location,
PULSE is not as precise as PITCH mode. Pitch and Pulse modes both have the same
performance.
Press
or
to switch from one mode to another.
Choose from one of the 3 factory pre-set programs in the menu to create your own custom program
which can then be saved as (prg 4).
Choose the program that you want modified, press
or
Press
, modify your settings and save them by pressing
. Prg. 4 is created.
The 4 programs on the WS6 are separate from the programs inside the pinpointer. When used inde-
pendently the MI-6 (unpaired) will always use its factory programs.
Programs and Save
In Option > Pairing > Pinpointer > Select, choose
RESEARCH
and press
.
The Pinpointer will ring and flash within a radius of 25 meters, even if switched off and missing after
several weeks.
Recover a lost MI-6
Improve localisation and reduce sensitivity on the fly: Recalibrate near the object when it sounds;
MI-6 active display screen
you will automatically reduce the detection zone and localise far better. Retrieve full sensitivity by press-
ing briefly away from metal. On mineralized soil, recalibrate on contact with the soil.
AUDIO
PITCH
TONE
1582
HZ
SENSITIVI.
45
Target zoom screen
Program N°
PRG 2
Battery MI-6
Access to:
SENS - TONE - AUDIO
