XPAND3DCinemaIREmitterSystem
XPAND3DIRemittersystemgeneratestheinfraredsignalthatsynchronizestheactive3Dglasseswith
the digital projector.The family of emitters consists of four members and a sync distribution
module:
AE210‐Emitter,Long‐Range,NarrowAngle(Requires
theAD1000forpowerandsignal)
This is a powerful emitter built in a small form factor,
designed to be mounted either in the theater or in the
projection booth behind a standard projection window
and aimed at the screen. Small to medium size theaters
need two emitters. And, for large theaters and theaters
withabalcony
consultanXPANDrepresentative.(Upto4unitscanbeinstalle d toincreasecoverage
or provideredundancy. )It contains 280high‐power,narrow‐angle(
±10°), IRdiodes and consumes
fivewattsof power in activeoperation.The unitincludesalaser pointer that can beturned on to
align it with the screen. It’s dimensions are 12.0”(304.8 mm)x 2.2”(55.9 mm)x1.5”(38.1 mm)
(width/height/depth).Itweighs1.5pounds(.68Kg).
Thenarrowa ngle emitterisdesignedto
bepla cedneartheprojectorandaimedatthescreen.The
IRsignal willbe reflectedback tothe audiencefrom thescreen.The narrowangle ofcoveragewill
insurethattheIRenergyisconcentratedonthescreen,notthewallsandceilingwhichmayabsorb
ratherthanscatter
it.
AE225‐Emitter, Long‐Range, Wide Angle (Requires
theAD1000forpowerandsignal)
This is a powerful emitter built in a small form factor,
designed to be mounted either in the theater or in the
projection booth behind a standard projection window
and aimed at the screen.Small to medium size theaters
need two emitters. And, for large theaters and theaters
witha
balconyconsultanXpandrepresentative.(Upto4unitscanbeinstalledtoincreasecoverage
orprovideredundancy.)Itcontains280high‐power,wide‐angle(
±25°),IRdiodesandconsumesfive
wattsofpowerinactiveoperation.Theunitincludesalaserpointerthatcanbeturnedontoalignit
with the screen. Its dimensions are 12.0”(304.8 mm)x 2.2”(55.9 mm)x1.5”(38.1 mm)
(width/height/depth).Itweighs1.5pounds(.68Kg).
