Thewideangleemittershouldbeusedifthegeometryoftheroomissuchthata+/‐10degreecone
ofradiationwillcoveronlyasmallportionofthescreen.Italsomaybeplacednearthescreenand
aimedattheaudience.
AE110‐Emitter,Mid‐Range,NarrowAngle
This is a medium range emitter designed for small theaters and
screening rooms with up to 100 seats.It is designed to be placed
near the projector and aimed at the screen.It contains 56 high‐
power,narrow‐angle (
±10°),IR diodesand consumesfourwattsof
power in active operation.It’s dimensions are 4.4”(111.8 mm)x
1.4”(35.6 mm)x 3.0”(76.2mm), (width/height/depth).It weighs 6
ounces(.17Kg).
AE125‐Emitter,Mid‐Range,WideAngle
This is a variation of the Medium range emitter designed to be
mountedatthefrontof thetheaterandaimedattheaudience.It
provides fill coverage in special situations such as very wide
theaters where bouncing the IR signal off the screen proves
inadequate.Itcontains56high‐power,
wide‐angle(±25°),IRdiodes
and consumes four watts of power in active operation.It’s
dimensions are 4.4”(111.8 mm)x 1.4”(35.6 mm) x 3.0”(76.2 mm),
(width/height/depth).Itweighs6ounces(.17Kg).
AD1000‐SyncDistributionModule
The Distribution Module receives the frame sync signal from the
projector or other source, converts it to X
PAND’s proprietary
synchronizationpulsecodeandsendsittotheIRemitterarrays.It
also supplies power to the emitter arrays and monitors their
performance.It can control up to four IR emitter arrays
simultaneously.InadditiontotheexternalIRarrays,theunithasits
ownsetofIRemitters
thatwillfloodtheprojectionboothwiththe
IRsignal.TheseIRdiodescanbeturnedoffifdesired.Themoduleisdesignedtobe mountedonthe
frontwall oftheprojectionbooth.Itsdimensionsare8.6”(218,4mm)x4.2”(106.7mm)x2.3”(58.4
mm),(width/height/depth).Itweighs15ounces
(.43Kg)
Toconservepowerandextendlife,thedistributionmoduleactivatestheIRemitterarraysonlyifthe
framesyncsignalisofafrequencyhigherthan36Hertzandlessthan80Hertz.3Dmoviesuseasync
rateof48to72Hertzwhile2Dmoviesusea
syncrateof24Hertz.Forthisreasontheunitdoesnot
havetobedeactivatedwhen2Dmoviesarebeingshownortheprojectorisidle.
