Ports and Buttons
Power plug, on/off switch and ports are located on the back and side of the
Xplornet Hub.
Side
Buttons Description
USB
USB2.0 host port in right panel: Used for the
USB storage device, or printer
Back
Ports Description
Phone1~Phone2 RJ-11 port is used to connect to the phone through the telephone line
LAN1~LAN4
RJ-45 port is used to connect the modem to computer or other network
devices
WAN
RJ-45 port is used to connect to your Xplornet modem
WPS
WLAN Protected Setup
Reset
Reset button should not be used unless advised by an Xplornet
representative. This button is used to restore the factory default settings
when pressed for more than 5 seconds.
WLAN Turn the WLAN on or turn off
Power Power supply port is connected to the power adapter
On/Off Power switch. Power on or power off the Hub
