Installing the XPower 1500
975-0166-01-01 3–13
Chassis Ground Screw
Xantrex recommends that you attach the cable to the chassis ground
screw with a ring terminal. This procedure will ensure that the wire does
not slip off the chassis ground screw.
To connect the cable to the chassis ground screw:
1. Make sure the inverter’s On/Off switch is in the Off position.
2. Remove chassis ground screw and star washer using #2 Phillips
screwdriver.
3. Strip 1/2" (13 mm) to 3/4" (19 mm) of insulation from one end of
each cable.
4. Attach the ring connector that will join the cable to the chassis ground
screw. The connector you use must create a permanent, low-
resistance connection. (See “Materials” on page 3–10.)
5. Fit the chassis ground screw through the star washer and the ring
connector back into the screw opening.
6. Tighten the chassis ground screw.
Connecting the DC Cables
Consult Figure 3-1, “Configuration for Normal Loads” on page 3–2, or,
Figure 3-2, “Configuration for Heavy Loads” on page 3–3, for additional
details that are specific to your installation.
To connect the DC cables:
1. Make sure the inverter’s On/Off switch is in the Off position.
If using the supplied cable assembly, go to step 6.
2. Strip 1/2" (13 mm) to 3/4" (19 mm) insulation from one end of each
cable. The amount stripped off will depend on the terminals chosen.
3. Attach the connectors that will join the cables to the battery,
Disconnect/Battery Selector switch, and fuse block. The connectors
you use must create a permanent, low-resistance connection.
If you are using crimp connectors, use the tool recommended by the
terminal manufacturer. Make sure no stray wires protrude from the
Important:
Use the supplied cable assembly if operating appliances with a
combined power requirement of less than 1000 W.
If operating appliances with a combined power requirement of greater than
1000 W, select DC cables according to Table 3-1 on page 3–7.
