A–1
A Specifications
Appendix A contains electrical performance and physical specifications
for the XPower 1500.
Electrical Performance
Physical Specifications
Specifications are subject to change without notice.
Electrical performance XPower 1500
Output power at 77 º F (25 ºC) ambient
temperature and 12 VDC input:
• Maximum continuous output power
• Maximum surge power
1500 W
3000 W
Output voltage 115 VAC RMS ± 10 VAC
Output waveform Modified sine wave
Output frequency 60 Hz ± 4 Hz
Input voltage 10.5–15.0 VDC
Low voltage alarm 11.0 V
Low voltage cutout 10.5 V
Overvoltage cutout 15.0 V
Optimum efficiency 90%
No load current draw <0.3 ADC
Physical XPower 1500
Length 13.9 inches (35.3 cm)
Width 6.0 inches (15.2 cm)
Height 3.0 inches (7.6 cm)
Weight 5.6 lbs (2.55 kg)
