Xray T3 User Manual

18
ROLL-CENTER ADJUSTMENT
902306
SH M3x6
902314
SH M3x14
307455
PB 5mm
901304
SB M3x4
303123-O
SHIM 3x6x2
902310
SH M3x10
EU RUBBER-SPEC
0° OUTBOARD TOE-IN UPRIGHTS
LEFT UPRIGHT = RIGHT UPRIGHT
L=R
L=R
L=R
(54 mm)
L2
L1
(56.5 mm)
EU
EU
RUBBER-SPEC
RUBBER-SPEC
US FOAM-SPEC
US FOAM-SPEC
5. FRONT & REAR TRANSMISSION
TIGHTEN GENTLY
TIGHTEN GENTLY
"1R"
US FOAM-SPEC
Use 2x alu shim 3x6x2mm on each side
(total thickness = 4mm).
EU RUBBER-SPEC
Use 2x alu shim 3x6x2mm on each side
(total thickness = 4mm).
"1L"
3x14mm
3x14mm
ALU SHIM
3x6x2mm
ALU SHIM
3x6x2mm
INITIAL POSITION
OPTIONAL 1-HOLE REAR UPRIGHTS
INITIAL POSITION
Use outer hole
Use inner hole
An optional 1-hole rear upright is
available for fine tuning. This optional
upright may be used on high-traction
tracks or tracks with long sweepers,
since the position of the center hole
will allow faster driving through those
corners because of better cornering
speed.
4
2
1
3
4
2
1
3
4
2
1
3
4
2
1
3
Quick Roll Center™ positions guideline
for use in the T3 SET-UP SHEET.
Qu
ic
k
Ro
ll
C
en
te
r
™
guideline
p
os
it
io
ns
Quick Roll Center
TM
tabs in upper inner holes
INITIAL POSITION
4
2
1
3
4
2
1
3
Quick Roll Center
TM
tabs in lower outer holes
INITIAL POSITION
4
2
1
3
4
2
1
3
US FOAM-SPEC
EU RUBBER-SPEC
1:1
25 mm
2x
1:1
25 mm
2x
After you tighten the screw
into the upright, pull the
linkage upward so the ball
joint " snaps " onto the pivot
ball. The whole assembly
should move freely.
DETAIL STEP
"CLICK"
