Xray T3 User Manual

19
ROLL CENTER ADJUSTMENT
902306
SH M3x6
902314
SH M3x14
307455
PB 5mm
901304
SB M3x4
ALU SHIM
3x6x1mm
L1L2
EU RUBBER-SPEC (54 mm)
US FOAM-SPEC (52.1 mm)
L=R
L=R
EU RUBBER-SPEC
EU RUBBER-SPEC
US FOAM-SPEC
US FOAM-SPEC
"4L"
"4L"
"4R"
"4R"
TIGHTEN GENTLY
TIGHTEN GENTLY
1:1
23 mm
2x
1:1
23 mm
2x
3x6mm
3x6mm
3x14mm
3x14mm
5. FRONT & REAR TRANSMISSION
Quick Roll Center
TM
tabs in lower outer holes
INITIAL POSITION
US FOAM-SPEC
4
2
1
3
4
2
1
3
Quick Roll Center
TM
tabs in upper inner holes
INITIAL POSITION
EU RUBBER-SPEC
4
2
1
3
4
2
1
3
After you tighten the screw
into the upright, pull the
linkage upward so the ball
joint " snaps " onto the pivot
ball. The whole assembly
should move freely.
DETAIL STEP
"CLICK"
