ACKERMANN ADJUSTMENT
ANTI-ROLL BARS
ADJUSTMENT
307455
PB 5mm
902310
SH M3x10
901308
SB M3x8
901303
SB M3x3
901304
SB M3x4
902310
SH M3x10
2x
2x
1:1
US FOAM-SPEC
EU RUBBER-SPEC
5. FRONT & REAR TRANSMISSION
3x3mm
3x3mm
3x4mm
FREE MOVEMENT
FREE MOVEMENT
1.5mm
ASSEMBLY VIEW
When the bars are set, verify that both sides move at the same
time. If yes, the bars are set up correctly. If not, make sure that both
downstops are the same and that the bar wire is flat.
Only tighten enough to remove excessive
free play; anti-roll bar must still move freely.
Wire should be flush
with end of pivot ball.
L=R
3x4mm
28mm
27mm
0mm
INITIAL POSITION
L=R
3x10mm
3x10mm
