36
903310
SFH M3x10
903310
SFH M3x10
REARWARD
FRONTWARD
CENTER
(INITIAL SETTING)
BODY POST ORIENTATION
It is important to use the same body setting
(rearward and center) on both front and
rear body posts at the same time.
This new, innovative feature allows the
adjustment of body position for all kind
of surfaces, traction conditions, touring
classes, using only one body. There are
THREE different body positions possible;
rearward, center, and forward. Depending
on conditions, the body post positions can
be easily changed which allows the body to
be moved.
• The body in the REARWARD POSITION
makes the car super stable and very
easy to drive. It makes the car easier to
drive in chicanes and more predictable
in high-traction conditions.
• The body in the CENTER POSITION
makes the car more aggressive and
steer faster, but is a slightly more
difficult to drive in low-grip conditions.
• The body in the FORWARD POSITION
is the most aggressive. It makes the car
steer a lot, but is more difficult to drive
when the traction is high or when the
track has a lot of chicanes.
FRONT BODY MOUNT SET
#301322 0mm INCLUDED
#301323 +1mm OPTION
#301324 +2mm OPTION
FRONT ECC. BODY MOUNT SET
#301326 0mm OPTION
#301327 +1mm OPTION
#301328 +2mm OPTION
7. FRONT & REAR ASSEMBLY
903306
SFH M3x6
