4
To ensure that you always have access to the
most up-to-date version of the XRAY Set-up
Book, XRAY will now be offering only the digital
online version at our website at www.teamxray.
com. By offering this online version instead of
including a hardcopy printed version in kits, you
will always be assured of having the most current
updated version.
Professional Multi Tool
(HUDY #183011)
SYMBOLS USED
L=R
2x
CA
OIL
Part bags used Assemble left and
right sides the
same way
Assemble in the
specified order
Pay attention
here
Assemble as
many times
as specified
(here twice)
Apply instant
glue
Cut off shaded
portion
Cut off
remaining
material
Tighten screw
gently
TOOLS REQUIRED
EQUIPMENT REQUIRED
TOOLS & EQUIPMENT INCLUDED NOT INCLUDED
Assemble front
and rear the same
way
Apply oil
Use special
tool
Silicone Shock Oil
(HUDY #106356 550cSt)
(HUDY #106361 600cSt)
Silicone Diff Oil
(HUDY #106431 3000cSt)
(HUDY #106471 7000cSt)
Air Filter Oil
(HUDY #106240)
Receiver Pack
LiPo Battery Pack
Transmitter .21ci (3.5cc) Engine
(FX K301 EC #650103)
Manifold & Exhaust Glow Plug IgniterStarter Box & Battery Pack
(HUDY #104500)
Steering and Throttle Servos
Battery Charger
Receiver Lexan™ Paint
Fuel + Fuel Bottle
(HUDY #104200)
Special Tool for all turnbuckles,
nuts (HUDY #181090)
Turnbuckle Wrench
(HUDY #181040 4mm)
(HUDY #181050 5mm)
Phillips 5.0mm
(HUDY TOOLS)
Socket 5.0/5.5mm
(HUDY TOOLS)
Allen 1.5/2.0/2.5/3.0mm
(HUDY TOOLS)
17mm Wheel Nut Tool
(HUDY #107570)
Side Cutters
(HUDY #189010)
Body Reamer
(HUDY #107600)
or
(HUDY #107601)
Cross Wrench
(HUDY #107581)
Flywheel Tool
(HUDY #182015)
Scissors
(HUDY #188990)
Needle Nose Pliers
(HUDY #189020)
➊ ➋ ➌
Apply grease Apply
threadlock
Ensure smooth
non-binding
movement
Use pliers Follow tip here
Arm Reamer 3mm/4mm
(HUDY TOOLS)
Graphite Grease
(HUDY #106210)
Threadlock CA Glue
Follow Set-up
Book
Use cleaner
or WD-40®
Time
Ball Allen 2.5mm
(HUDY TOOLS)
BOOK
SET-UP
BOOK
SET-UP
Pocket Hobby Knife
(HUDY #188981)
Electric Motor
& Pinion Gear
Speed Controller
Double-sided Tape
(HUDY #107875)
Electric
Nitro
Snap Ring Pliers
(HUDY #189040)
Tires & Wheels
To Next Page
