15
TOE-IN
ANTI-SQUAT
ROLL CENTER DOWNSTOP
WHEELBASE
TRACK WIDTH
903414
SFH M4x14
901408
SB M4x8
353371
SHIM 4x10x2
HARD
SUSPENSION ARMS
(HUDY #107644)
ARM REAMER
If the suspension arms DO NOT
move freely, use a HUDY Arm
Reamer to resize the holes.
➊
➊
➋
➌
➌
➍
➍
➎
2mm
4x8mm
RR
RF
All possible mounting
alternatives of eccentric bushings.
INITIAL SETTING
RR
Check for free movement.
DETAIL
DETAIL
ECCENTRIC BUSHINGS HAVE TWO DIFFERENT OFFSETS FROM THE CENTER.
Middle position = 0.5 mm or 0.5° from center.
Outer position = 1mm or 1° from center.
The XRAY rear alu lower suspension holders provide even greater range of adjustment for the rear suspension. Using different combinations of eccentric bushings, fine adjustment of rear anti-squat, rear
toe-in, rear roll center, and rear track-width can be obtained. For more information about the influence of rear anti-squat, rear toe-in, rear roll center and rear track width on car handling, please refer to
HUDY Off-Road Set-up Book (#209099).
The tables describe the amounts of rear anti-squat, rear toe-in, rear track-width change depending
on the combinations of eccentric bushings used with 0 and 1mm, 1° offset. The 0.5mm, 0.5° represents
the half change.
Anti-Squat Example:
0(RR) - 0 (RF) = 3°
0(RR) - 0.5 (RF) = 3.5°
0(RR) - 1 (RF) = 4°
ANTI-SQUAT ROLL CENTER TRACK-WIDTH TOE-IN
RR RR RR RRRF RF RF RF(°) (mm) (mm) (°)
=3°
=4°
=2°
=4°
=3°
=5°
=2°
=3°
=1°
= 3°
= 3.5°
= 4°
=0
mm
=1mm
=-1mm
=308
=306
=310
=3°
=4°
=2°
=2°
=3°
=1°
=4°
=5°
=3°
BOOK
SET-UP
INITIAL SETTING
RF
0.5º1º
0.5º1º
2.0mm
DOWNSTOP SETTING
DETAIL
2.0mm Allen
#902407
Downstop screw
for fine tuning.
NOTE
ORIENTATION
NOTE
ORIENTATION
X-HARD / GRAPHITE
SUSPENSION ARMS
MEDIUM
SUSPENSION ARMS
RF
RR
DO NOT use OUTER positions.
0.5º
0.5º
1º
1º
RF
RR
DO NOT use INNER positions.
0.5º
0.5º
1º
1º
RF
RR
All positions are available.
0.5º
0.5º
1º
1º
3. REAR SUSPENSION
Push bushing into suspension
holder until flush.
