Xray XT4 User Manual

25
ROLL CENTER
CAMBER
ALU CONICAL SHIMS
#362280 SILVER INCLUDED
#362280-K BLACK OPTION
#362280-O ORANGE OPTION
961025
S 2.5
902254
SH M2.5x4
S 2.5
S 2.5
TIGHTEN
GENTLY
TIGHTEN
GENTLY
4. FRONT TRANSMISSION
2x
2x
2x
L=R
L=R
L=R
52.5mm
2x
L=R
10mm
THREAD
8mm
THREAD
L=R
If the C-hub does not move freely, use a HUDY Arm Reamer to
resize the hole.
ARM REAMER
(HUDY #107633)
CONICAL SHIM
3x6x2mm
NOTE
ORIENTATION
NOTE
ORIENTATION
362280
CON. SHIM 3x6x2
960030
N M3
Check for free
movement
ALU NUTS M3
#296530-B BLUE OPTION
#296530-K BLACK OPTION
#296530-O ORANGE OPTION
#960030 STEEL INCLUDED
#960031 SILVER OPTION
INITIAL SETTING
L=R
DETAIL
10mm
THREAD
8mm
THREAD
THREAD
THREAD
Install the pivot balls with Professional
Multi Tool (HUDY #183011)
