XSY AT2 - Multi Speed Frequency Comparison Table

3.
Multi
-
speed input Frequency control table
：
Port
Functional
description
Instructions
COM Common GND
VL1
Externalanalog
voltage
input
0-5V/10VAnalogvoltageinput
CI
External current signal
input
4-20mA Current input
SP1 Open-collector output 1
SP2 Open-collector output 2
5V/10V 5V/10V power output
supply 5V/10V 20mA power output
TC Relay output C
250VAC 5A/30VDC 3A
TAand TB Normal Close,TAand TC
NormalOpen
TB Relay output B
TA Relay output A
Section
speed input 1
Section
speed input 2
Section
speed input 3
Original
Frequency
Main Speed 1 1 1 50
Section speed 1
1 1 0 45
Section speed 2 1 0 1 40
Section speed 3 1 0 0 35
Section speed 4 0 1 1 30
Section speed 5 0 1 0 25
Section speed 6 0 0 1 20
Section speed 7 1 1 1 15
Note
：
0 means input Port connect with COM, 1 means
disconnect.
