Xterra iPOWER+ - Page 39

39
HARDWARE STEP 1
HARDWARE STEP 2
HARDWARE STEP 3HARDWARE STEP 4
ASSEMBLY TOOLS
#73.Ø10 × 2T
Split Washer
(2 pcs)
#81.Ø3/8"× 1.5T
Flat W asher
(2 pcs)
#98.3/8"×2-3/4"
Button Head Socket
Bolt (2 pcs)
#90.Ø8 × 1.5T
Split Washer
(4 pcs)
#79.Ø5/16"× 1.5T
Flat W asher
(4 pcs)
#94.5/16"×3/4"
Button Head Socket
Bolt (4 pcs)
#101.3.5×12mm
Sheet Metal Screw
(9 pcs)
#83.M5×15mm
Phillips Head Screw
(4 pcs)
