Xterra iPOWER+ - Parts List

60
PARTS LIST
No.
Description
Qty
1
Main Frame
1
2
Frame Base
1
3
Incline Bracket
1
4
Left Upright
1
5
Right Upright
1
6
Console Support
1
7
Handgrip
2
11
Belt Guide
2
12
Motor Bracket
1
13
Drive Motor
1
14
Drive Belt
1
15
Running Deck
1
16
Running Belt
1
17
Front Roller W/Pulley
1
17~3
Magnet
1
18
Rear Roller
1
20
Console Assembly
1
20~1
Console Top Cover
1
20~2
Console Bottom Cover
1
20~3
Square Magnet Stop Plate
2
20~4
300m/m_Safety Switch Module W/ Cable
1
20~5
Console Display Board
1
20~6
PAD Support Frame
1
20~7
3 × 10m/m_Sheet Metal Screw
2
20~8
2.3 × 6m/m_Sheet Metal Screw
12
20~9
3.5 × 12m/m_Sheet Metal Screw
18
20~10
Face Plate Lens Cover
1
20~11
Key Board (AK0456A incline)
1
20~12
Key Board (AK0456B speed)
1
20~13
Receiver, HR (Optional)
1
20~14
400m/m_Receiver Connecting Cable (Optional)
1
20~15
Bluetooth
1
21
Motor Top Cover
1
22
Rear Adjustment Base (L)
1
23
Rear Adjustment Base (R)
1
24
Frame Base Cover (L)
1
25
Frame Base Cover (R)
1
26
Top Motor Cover Plate
1
27
30 × 60 × 2T_Square End Cap
2
28
Ø4.5 × Ø30 × 26T_Rubber Foot Pad
2
29
Cylinder
1
30
Transportation Wheel
2
31
Foot Rail
2
32
Rubber Foot
6
33
20 × 40m/m_Square End Cap
2
34
Incline Motor
1
35
3/8” × 1-3/4”_Hex Head Bolt
1
36
Power Socket
1
37
Breaker
1
