Xterra TRX3500 User Manual

21
Part Number Part Description Qty per unit
1
Main Frame 1
2
Frame Base 1
3
Incline Bracket 1
4
Right Upright 1
5
Left Upright 1
6
Console Support 1
7
Outer Slide 1
8
Inner Slide 1
9
Handrail Support 1
10
Incline Motor 1
11
Drive Belt 1
12
Motor Bracket 1
13
Drive Motor 1
14
Running Belt 1
15
Running Deck 1
16
Front Roller W/Pulley 1
17
Rear Roller 1
18
Deck Cross Brace 2
20
Locking Knob 1
21
Console Assembly 1
21~1
Console Top Cover 1
21~2
Console Outer Cover 1
21~3
Front Console Cover (Inner) 1
21~4
Interface Board 1
21~5
Square Magnet Stop Plate 2
21~6
Drink Bottle Holder 2
21~7
Wind Duct 1
21~9
400m/m_Bluetooth 1
21~12
150m/m_Safety Switch Module W/ Cable 1
21~13
Console Display Board 1
21~14
Key Board (L)-AK0464-K04-01 1
21~15
Speaker Grill Anchor 6
21~16
250m/m_Speaker W/Cable 1
21~17
500m/m_Speaker W/Cable 1
21~19
Key Board (R)-AK0464-K05-01 1
21~20
1000m/m_Handpulse Wire(Upper) 1
21~21
1000m/m_Handpulse Wire(Upper) 1
21~22
Sound Board W/Cable 1
21~23
2.3 × 6m/m_Sheet Metal Screw
38
21~24
3 × 10m/m_Sheet Metal Screw 6
21~25
3.5 × 12m/m_Sheet Metal Screw 31
21~26
3.5 × 50m/m
_
Sheet Metal Screw 4
21~28
Key Board-AK0464-K02 1
21~29
Key Board-AK0464-K03 1
PARTS LIST

Xterra TRX3500 Specifications

General

Speed Range	0.5 - 12 mph
Running Surface	20" x 60"
Weight Capacity	350 lbs
Foldable	Yes
Display	LCD
Heart Rate Monitoring	Grip Pulse
