Xterra TRX4500 User Manual

25
Part Numbe
r
Part Descri
p
tion Qt
y
p
er unit
127
M10 × 8T
_
N
y
loc Nut 2
128
M5 × 10m/m_Phillips Head Screw 3
130
Wire Clamp 1
140
4 × 25m/m_Sheet Metal Screw 2
141
Foot Rail Back Plate 2
143
Chest Strap (Optional) 1
151
400m/m_Audio Cable 1
152
Controller Back Plate 1
153
3 × 8m/m_Sheet Metal Screw 6
155
Link 1
156
Link Shaft 1
157
Shaft Bushing 2
158
Fastening Bracket 2
159
Clevis Pin 1
160
Fastening Bushing 1
161
Dual Torsion-Spring 1
162
Release Lever 1
163
ChenChin Torsion-Spring 1
164
Steel Cable Tension Spring 1
165 855m/m_Steel Cable 1
166
M3 × 10m/m_Phillips Head Screw 1
167
M5 × 20m/m_Phillips Head Screw 1
168
5/16" × 42L_Button Head Socket Bolt 1
169
M5 × 5T_Nyloc Nut 1
170
M3 × 2.5T_Nut 1
171
Ø5 × Ø10 × 1.0T_Flat Washer 2
172
Ø5 × Ø13 × 1.0T_Flat Washer 1
173
M3_Split Washer 1
175
Rubber Foot 4
177
200m/m_Connecting Wire (White) 1
178
Filter 1
179
Choke 1
180
600m/m_Connecting Cable Of Motor 1
181
Non-Slip Rubber 2
182
Ø13m/m_Bolt Cap 5
183
Ø14m/m_Bolt Cap 3
184
Ø19m/m_Bolt Cap 2
