STEP 15: REAR SUSPENSION
(148560) Flanged Lock Nut 3mm -- 2
STEP 16: REAR SWAY BAR MOUNTS
(149293) Threaded Stud 3 x 12mm -- 2
149293
149293
149293
149293
149293
(148509) Cap Screw 3 x 20mm -- 2
(149901) Hinge Pin 4 x 67.2mm -- 2
(148511) Cap Screw 3 x 25mm -- 2
(148638) Button Head Screw w/Threadlock 4 x 12mm -- 2
149307
149915
148638
148509
149901
Step 14
149503
148560
Step 12
Step 14
148511
