STEP 13: REAR UPPER SUSPENSION ARMS
(149493) Turnbuckle 5 x 36mm -- 2
STEP 14: REAR LOWER SUSPENSION ARMS AND HUBS
149543
149493
149543
149497
149497
13.2mm
(148648) Cap Screw 3 x 45mm -- 2
(148511) Cap Screw 3 x 25mm -- 2
(148574) Grub Screw w/Threadlock 5 x 5mm -- 2
(148567) Grub Screw 4 x 10mm -- 2
(148558) Lock Nut 3mm -- 4
(149305) Pin 2.5 x 16.8mm -- 2
(148624) Shim 8 x 12 x 0.2mm -- 2
(149563) Ball Bearing 8 x 16 x 5mm -- 4
Step 13
149483
148511
149563
148624
148648
149305
148574
149305
149291
148558
149483
148558
148567
149301
149503
149563
