Page 32
STEP 21: STEERING SERVO
(148632) Button Head Screw 3 x 10mm -- 6
STEP 22: STEERING SERVO MOUNTING
(148640) Flat Head Screw 3 x 10mm -- 4
148632
148632
150038
149884
148632
148632
Step 21
Step 20
148640
148640
ST-CH1
ExpLODED vIEW ASSEmBLY DRAWINGS
Continued On Next Page
