STEP 23: BRAKE PLATE AND CENTRE DIFFERENTIAL
(148636) Button Head Screw 3 x 25mm -- 2
STEP 24: MOTOR MOUNTING
(148570) Grub Screw w/Threadlock 4 x 4mm -- 1
(148527) Button Head Screw w/Threadlock 3 x 12mm -- 4
148636
149281
149282
Step 1
149281
149859
148570
150033
148527
150031
145651
ExpLODED vIEW ASSEmBLY DRAWINGS
Continued On Next Page
