STEP 26: POWER SYSTEM MOUNTING
(148645) Flat Head Screw w/Threadlock 4 x 10mm -- 2
(148646) Flat Head Screw 4 x 15mm -- 2
Step 25
Step 22
148646
148645
A
B
C
Black
Red
Yellow
ExpLODED vIEW ASSEmBLY DRAWINGS
Blue
Yellow
Orange
Continued On Next Page
