Page 41
STEP 34: FRONT AND REAR SHOCKS
(149840 / 149841) Lock Nut 2.6mm -- 4
(149840 / 149841) Washer 2.5x5.9x0.5mm -- 4
(149850) O-Ring 3mm -- 4
(149850) O-Ring 3.5mm -- 8
(149840) Shock Shaft 3.5 x 52mm -- 2
(149840 / 149841) O-Ring 2.5 x 1mm -- 4
(149841) Shock Shaft 3.5 x 61mm -- 2
(149846) Shock Body 14 x 45mm -- 2
(149847) Shock Body 14 x 53mm -- 2
149840
149840
149840
149840
149840
149846
149846
149850
149850
149850
149850
149846
149942
149942
149847
149850
149850
149850
149850
149847
149847
149841
149841
149841
149841
149841
3.5mm 3.5mm
3.0mm
3.5mm 3.5mm
3.0mm
ExpLODED vIEW ASSEmBLY DRAWINGS
Continued On Next Page
To Next Page
