Xtralis VESDA LCD Programmer Product Guide Xtralis VESDA
®
34 www.xtralis.com
103. Factory Defaults -
• Factory Defaults - To restore factory defaults, highlight Restore and press .
• Defaults OK - Highlighting Start and pressing will acknowledge Factory
Default settings and clear faults 12, 30, 31, 33, 34, 35, 38, 57, 68 and 72.
DST
ADM
104. Communications - The Communications screen allows settings for:
• Net Delay - This function sets the maximum time for a message to travel around
the network and return to the originating device. If the message does not return
within the prescribed time, it is presumed lost and will be resent
• Prof. Port - This allows you to assign a preferred port for communication
• Health Check - This function sets the frequency of health-check messages sent
around the system
• Open-ended - In an open-ended VESDAnet loop select the port that is not
connected to the VESDAnet loop.
DST
105. Miscellaneous -
• UL Version - A against this indicates that the device is set to meet UL
specifications.
• Latch Alarms - This provides a YES/NO option to latch/unlatch all Alarms
• Latch Faults - This provides a YES/NO option to latch/unlatch all Faults
• GP Input - The GP Input permits setting the general purpose input functions.
For details on GPI functions please refer to the VLP Detector Guide.
ADM
DST
106. Ancillary Devices - Should be put under the same flow line as detectors. Select
the device by highlighting it and press .
USR
107. Display/Relays - Should be put under the same flow line as detectors. Select the
Display/Relay and press .
USR
108. Status - Displays the current status of the Display/Relay
• Faults - List of faults generated for Display/Relay connected to VESDAnet
• SW Version - Displays the software version of the Display/Relay
• Cfg Code - This is a configuration code set during production
USR
Scrn
No.
Description
Min.
Access
Level
↵
↵
Parameter Default Minimum Maximum
Network delay 15 seconds 10 seconds 45 seconds
Preferred port A N/A N/A
Health check 45 seconds 40 seconds 60 seconds
Open - ended none N/A N/A
Parameter Default
UL Version Enabled
Latch Alarm Enabled
Latch Fault Enabled
↵
↵
