109. Address Control - The four functions under Address Control are the same as the
functions performed by the buttons on the Display Module.
• Mode - This controls the mode of the LCD Numerical display on the Display.
Use the +, -, and the key to change the mode
- Current Sector - Display the First Alarm Sector in VLS Display
- Sensitivity - Displays the sensitivity level
- Smoke Level - Displays the current smoke level
- Address Number - Displays the assigned VESDA Zone number for the
detector
• Silence - Silences beeping sound of the detector
• Scan - Selecting this option in a VLS Display commences a Scan sequence of
the assigned VLS Detector
• Reset - Resets faults
• Isolate - Starts and stops isolation of the detector
USR
110. Address Number - Assign the VESDA Zone number to a Display/Relay. ADM
111. Location - Allocate a VESDA Zone name and location and assign these to the
respective Display/Relay.
ADM
112. Power Supply Number - Input the number of the power supply that is assigned to
the detector. If the VESDA Intelligent Power Supply is not being used enter “0”.
ADM
113. Button Lockout - This screen provides the option to Lock or enable the buttons on
a Display.
ADM
114. Relays/Disp Connected - Use the screen to enter the number of relays connected
to the Display. It also indicates if the detector is a VLS.
DST
115. Relay Setup - This displays sub-menus for:
• Relay Startup Mode (only used on a display with relays assigned)
• Latching
• Beeper
• Relay Assignments (only used on a display with relays assigned)
ADM
116. Relay Startup Mode - Displays the energize/de-energized condition for each relay.
If required, use the
+ - and keys to change the energized/de-energized state of
relays.
ADM
Scrn
No.
Description
Min.
Access
Level
↵
↵
Parameter Default
Relay Startup Mode
Relay 2 & 3 energized Energized
Relays 1, 4-7 (4-12) De-Energized
