7. Parts Breakdown
1 647252772000 Strainer Cover 1
2 5431042080 Strainer Cover O-Ring 1
3 47252704001 Basket 1
4 47252703080 Strainer Housing 1
5 47252705080 Clip 1
6 5431029080 Strainer Housing O-Ring 1
7 5212016000 Screw ST5.5*25 8
8 47252702080 Diffuser 1
9 64727297130 Impeller 1
10 5431040080 Housing O-Ring 1
11 5028003000 Seal Assembly 1
12 47252701080 Pump Housing 1
13 47252708080 Motor Mounting Plate 1
14 5023410000 Motor 1
15 41038005 Mounting Foot 1
16 5224025000 Screw M5*14 4
17 5432002080 O-Ring 1
18 48860105080 Drain Plug 1
12
