Brief Introduction
This variable speed pump
is designed to operate your swimming pool filtration system as well as your spa,
waterfall, cleaner, heater, salt chlorine system and other water applications.
Using the control panel, you can run your pump on one of three scheduled programs:
1. Regular mode: use three quick start buttons.
ECO (default 1500RPM)/CLEAN( default 2400RPM)/BOOST( default 3250RPM), and then adjust the pump
to run at the your preferred.
2. Mode 1: 16 hours for each clean cycle.
3. Mode 2: 24 hours for each clean cycle.
The control panel also has LED indicators for speed as well as alarm indicator and error code to warn the
user on the voltage problems, excessive temperature, over current and freeze protection etc.
1. Features of LED Control Panel
1!Display and change time.
2!Display and change running speed.
3!Quick-start button of ECO/CLEAN/BOOST to run on different speeds.
4!MODE1/MODE2
for scheduled programs (16 hours or 24 hours clean cycle).
5!Re-start and reset to normal schedule after over current, over voltage, over heat, or unexpected
power off.
6!Keep records of scheduled programs for max 15 days after power off.
7!Run 5 minutes at high speed after the start
8!Step-by-step acceleration
and deceleration of the speed to extend the use life of the motor and
control panel
5
