XTZ 99 W12 DSP User Manual

12 / 26
6 IR
Infrared eye for possible remote control
Not in use
7 LCD Contrast
Adjust the contrast in the display
8 Volume knob
VOLUME
Adjust the main volume.
9 Balanced input
XLR
Balanced input.
10 Ground choice
Depending on equipment us "GRD" or "LIFT".
Only in use if you connected with XLR.
11 Low level input
RCA inputs.
12 RS 232 PC
connector
Connector for PC. For the PC-remote software.
The program is in price included but you
need to download it from www.xtz.se
13 Input selector
INPUT SELECTOR
Select input between: XLR ,RCA or High-level
input
14 Speaker input
SPEAKER INPUT
High-level input.
If your amplifier does not
have subwoofer output
use this input from your normal speaker output.
15 Power connector
Connector of main power.
16 Main switch
Main switch for main power.
17 Power switch
Select your local mains voltage.
230V in EU
110V in USA
