YABE 110T - Handling and Installation; Technical Features

14
1.4 TECHNICAL FEATURES
Fig. 2
1.5 HANDLING AND
INSTALLATION
The wood-cutter is supplied ready for use with
the knife already fitted. The machine can be
easily moved on flat surfaces by means of its
two wheels and gripping it firmly as shown in
Fig. 2.
Before installation read this booklet
through carefully and especially the safety
instructions given in paragraph 1.6.1.
Memorise the instructions and carefully
conserve this booklet.
ENGLISH - OPERATING INSTRUCTIONS
110T 110+PTO 110T+PTO
Transmission Volt/kW 400/3,0 Cardano 400/3,0
Thrust power t 10 10 10
Cutting height cm 55-70-110 55-70-110 55-70-110
Cutting speed cm/sec 4,8 6 4,8-6
Oil tank capacity Kg 14 14 14
Weight Kg 300 300 305
Weight Ø mm 300 300 300
Sound level: work station (A) dB 78.0 78.0 78.0
Acoustic power level LwA (A) dB 97,3 97,3 97.3
DIMENSIONS
Height mm 1600 1600 1600
Depth mm 1100 1100 1100
Width mm 730 730 730
